JFM MAGNIFIERS
JFM Magnifier is Luxo’s newest high-quality illuminated magnifier. Like the
WAVE+Plus Magnifier, manufactured in Europe, the JFM Magnifier is an ideal
medium-duty magnifier for inspection, assembly and rework applications.
? Instant-On Switch: Just a touch of a switch ignites the fluorescent tube instantly
and creates a “flicker-free” light that eliminates the stroboscopic effect on
machinery such as a lathe or drill press.
? Adjustable Neck moves the magnifier head vertically and horizontally to provide
total flexibility.
? Minimum Clearance Bracket allows for almost zero clearance (approximately ?”
clearance) between adjacent benches. It also provides more freedom of
movement by raising the swivel point of the magnifier 2” higher above the bench
surface. Its increased “jaw” size permits it to be clamped to surfaces up to
2.75” thick.
? 5” diameter lenses are mounted in a die-cast aluminum housing that is
non-corrosive and durable. The inside is finished in white to optimize and evenly
distribute light.
16115LG
? Optical-quality, white crown, 3-diopter (1.75X) or 5-diopter (2.25X) glass lens.
? 22-Watt Energy-Efficient Tube is protected by a heavy-duty clear diffuser which
provides cool, shadow-free light on any worksurface.
? Lamp diffuser cover.
? 30” or 45” reach external spring arm.
? Electronic ballast produces 15% greater light output.
? Operates on 115VAC.
? UL/CUL listed.
? 5 year warranty.
JFM Magnifiers
Part No.
16113
16115
16213
Description
JFM1A 3D
JFM1A 5D
JFM2A 3D
Lens Type
3-Diopter
5-Diopter
3-Diopter
Color
LG
LG
LG
Arm
Length
45"
45"
30"
Mounting Bracket
Edge Mount
Edge Mount
Edge Mount
16213LG
16215
JFM2A 5D
5-Diopter
LG
30"
Edge Mount
NOTE: Light Gray (LG)
7
